Bottom bracket bushing | Piaggio Ciao

swiing® revival Ø 9 mm wedge 3.5° pedal crank galvanized

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Color: silver · Thread type: M7x1 (standard thread) · Ø outside: 9 mm · Total length: 43 mm · Angle crank wedge: 3.5°

Pedals angular | Piaggio Ciao. SI, Bravo

Material: Plastic · Surface: ribbed · Color: black · Thread type: FG14.3 (9/16" 20G) · Drive: Outer edge · Width across flats SW: 15 mm · Total length: 118 mm · Width: 51 mm · Height: 29 mm · Reflectors: Yes

Stand 14 mm axle (1A quality) | Piaggio Ciao PX, C24

Manufacturer: Made in Italy · Material: Steel · Color: black · Surface: varnished · Stand base - center mount (A): 232 mm · Total width of stand base (B): 200 mm · Wide receptacle (C): 78 mm · Ø Receptacle (D): 14 mm · Wide upright foot (F): 20 mm · Total height: 250 mm

GPO control bearing set | Piaggio Ciao

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Color: silver · Bearing type: Bearing ring · Ø inside: 27 mm · Ø mounting frame: 30.05 mm · Ø outside: 41.4 mm · Ø outside: 42 mm · Thread type: FG25.4 (1" 24G) · Height: 10.5 mm · Height: 17 mm · Ø ball [inch] / [mm]: 5/32" (4.00 mm)

Cable set black | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Made in Germany · Material: Steel · Color: black · Quantity: 4 pcs · Ø Stranded wire: 1.25 mm · Ø Stranded wire: 1.5 mm · Ø Stranded wire: 1.8 mm · Outer shell length: 1200 mm · Outer shell length: 1250 mm · Outer shell length: 1300 mm · Outer shell length: 2000 mm · Nipple shape: Ball · Nipple shape: Barrel (transverse) · Nipple shape: Pears · Total length: 1350 mm · Total length: 1600 mm · Total length: 2180 mm

GPO chain tensioner | Piaggio Ciao

Manufacturer: GPO · Material: Plastic · Material: Steel · Color: black · Surface: galvanized (blue) · Color: silver · Number of teeth: 8 pcs · Ø outside sprocket: 33 mm · Total length: 64 mm · Width: 45 mm · Thread type: M8x1.25 (standard thread) · Number of fixing points: 1 pcs

GPO pedal cranks chrome 148 mm pair

Manufacturer: GPO · Material: Steel · Color: Chrome · Surface: chrome-plated · Crank length (center-center): 120 mm · Total length: 148 mm · Ø Pedal wedge: 9 mm · Thread type: FG14.3 (9/16" 20G) · Cranking (offset): 30 mm

GPO pedal axle 28 teeth keyway galvanized (1A quality) | Piaggio Ciao

Chain pitch: 1/2" x 1/8" · Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Color: silver · Number of teeth: 28 pcs · Ø outside: 130 mm · Total length: 234 mm · Wavelength from wreath: 48 mm · Wavelength from wreath: 183 mm · Ø Outer sprocket: 118 mm · Ø Pedal arm holder: 16 mm · Crank (wreath): 2.3 mm · Piaggio OEM number: 813424

GPO Support rubber fork swing arm | Piaggio Ciao

Manufacturer: GPO · Material: Rubber · Color: black · Ø outside: 7.9 mm · Ø mounting hole: 6.9 mm · Total length: 22.8 mm · Width: 16.25 mm · Height: 8.8 mm · Total height: 22.7 mm

Spacer tube pedal axle 44 mm | Piaggio Ciao

Manufacturer: Quenching · Ø inside: 16 mm · Nominal diameter inside: 16 mm · Ø outside: 18 mm · Total length: 44 mm · Piaggio OEM number: 163653 · Piaggio OEM number: 269152
